The AELAB AE-PM100 Polarizing Microscope performs accurate polarized light microscopy for detailed observation of anisotropic materials. Engineered for mineral, crystal, and material structure analysis, the AE-PM100 integrates a precision rotating stage, polarizing optics, and stable illumination.
The AELAB AE-PM100 Polarizing Microscope supports both educational and professional laboratory workflows by enabling qualitative and comparative analysis under polarized and single polarization modes.
The AELAB AE-PM100 Polarizing Microscope features a rigid optical frame with a 30° inclined, 360° rotatable monocular head. The instrument integrates a quadruplex nosepiece and a large-diameter rotating polarizing stage to ensure mechanical stability and precise angular positioning during microscopic examination.
The AELAB AE-PM100 Polarizing Microscope analyzes material structures by transmitting polarized light through specimens. The analyzer unit and Bertrand lens can be inserted or removed from the optical path, enabling both single polarization and crossed polarization observation for crystal interference and birefringence analysis.
The AELAB AE-PM100 Polarizing Microscope operates as a standalone optical system. Mechanical and optical components support integration with laboratory workflows for teaching, inspection, and qualitative material analysis.
The AELAB AE-PM100 Polarizing Microscope is used for mineral identification, petrographic analysis, crystalline structure observation, polymer stress analysis, and educational microscopy in geology, material science, and industrial quality control laboratories.
The AELAB AE-PM100 Polarizing Microscope is manufactured under controlled quality systems. Optical alignment, mechanical stability, and illumination performance are verified to support laboratory-grade polarized light analysis consistent with ISO and CE manufacturing practices.
Specifications :
| Items | Specification | AE-PM100 |
| Eyepiece | WF 10×-18mm (Cross, Reticule 0.1mm) | ● |
| WF 16×-13mm | ○ | |
| Non-stress
Achromatic Objective |
4× | ● |
| 10× | ● | |
| 40× (S) | ● | |
| 20× | ○ | |
| 60× (S) | ○ | |
| Mono Head | Inclined 30°, Rotatable 360° | ● |
| Nosepiece | Quadplex | ● |
| Analyzer Unit | 0-90°，It can be moved out of the optical path for single polarizing observe. | ● |
| Bertrand Lens | It can be moved out of the optical path. | ● |
| λ Slip | First Class Red | ● |
| 1/4λ Slip | ● | |
| Quartz Wedge | (Ⅰ-Ⅳ Class) | ○ |
| Revolving Round Stage | Rotatable 360°, Division 1°, Vernier division 6’，can be locked. Diameter Φ142mm | ● |
| Polarizing Attached Mechanical Stage | ○ | |
| Condenser | Abbe N.A. 1.25 | ● |
| Polarizing Unit | It can be moved out of the optical path. | ● |
| Illumination | 12V/20W Halogen Lamp | ● |
| 3W LED Lamp | ○ | |
Note:"●"InTableIsStandardoutfits,"○"IsOptionalAccessories
| Items | Specification | AE-PM100 |
| Eyepiece | WF 10×-18mm (Cross, Reticule 0.1mm) | ● |
| WF 16×-13mm | ○ | |
| Non-stress
Achromatic Objective |
4× | ● |
| 10× | ● | |
| 40× (S) | ● | |
| 20× | ○ | |
| 60× (S) | ○ | |
| Mono Head | Inclined 30°, Rotatable 360° | ● |
| Nosepiece | Quadplex | ● |
| Analyzer Unit | 0-90°，It can be moved out of the optical path for single polarizing observe. | ● |
| Bertrand Lens | It can be moved out of the optical path. | ● |
| λ Slip | First Class Red | ● |
| 1/4λ Slip | ● | |
| Quartz Wedge | (Ⅰ-Ⅳ Class) | ○ |
| Revolving Round Stage | Rotatable 360°, Division 1°, Vernier division 6’，can be locked. Diameter Φ142mm | ● |
| Polarizing Attached Mechanical Stage | ○ | |
| Condenser | Abbe N.A. 1.25 | ● |
| Polarizing Unit | It can be moved out of the optical path. | ● |
| Illumination | 12V/20W Halogen Lamp | ● |
| 3W LED Lamp | ○ | |
Note:"●"InTableIsStandardoutfits,"○"IsOptionalAccessories
