AELAB SHP Series Biochemical Incubator | Constant-Temperature BOD & Microbial Culture

This product can be widely used in the lab of the science research such as environmental protection sanitation epidemic prevention, farming and pasturage, drug inspection, aquatic product, the lab of the junior college academy and production department. It is the specialized constant temperature equipment for water analyzing, BOD assay, the bacteria, mildew, the culturing and storage of the microbial, vegetable planting and breeding experiment.

Features include a double screen and high luminance charactron display for direct viewing of set and actual values, adjustable shelf quantity and height, independent ultra-high temperature protection with working-state prompts, and environmentally friendly CFC-free refrigeration airflow.

⚙️ Design & Construction

The AELAB SHP Series biochemical incubator employs a forced-air refrigeration system with CFC-free airflow to stabilize chamber temperature. A high-luminance dual display presents setpoint and process values for precise monitoring. Adjustable Stainless Steel shelves support up to 25 kg (SHP-80) or 15 kg (other models) per shelf. The series offers chamber volumes from 80 L to 1000 L with robust casters for safe, mobile positioning.

🔬 Working Principle / Testing Method

The SHP Series regulates chamber temperature from 0–60 °C with 0.1 °C resolution. Users set the required incubation temperature and timing (0–99h59min). The controller maintains a constant environment with a wave degree of temperature of ±0.5 °C, enabling reproducible biochemical reactions such as BOD determination, microbial incubation, seed/plant germination, and general stability studies.

💡 Key Advantages

• 0–60 °C control range with ±0.5 °C stability for reliable biochemical incubation
• 0.1 °C resolution supports precise method development and verification
• Wide capacity coverage (80–1000 L) for routine testing to pilot workloads
• Dual high-luminance display enhances readability of setpoint and process values
• Independent over-temperature protection increases operational safety
• Adjustable shelves and multiple shelf positions optimize loading geometry
• CFC-free refrigeration airflow supports environmentally responsible operation

🔗 Connectivity & Integration

The catalog does not specify external interfaces (USB, RS-232, or printer). Data output options are therefore not listed.

🧠 Model Insight

🧪 Testing Applications

The AELAB SHP Series biochemical incubator supports environmental BOD analysis, microbial culture and storage, mildew/bacterial growth studies, seed and vegetable planting, breeding experiments, and general water-quality and stability testing in research, academic, and production laboratories.

Compliance & Quality Assurance

AELAB manufactures the SHP Series under strict quality control suitable for ISO/GLP-style laboratory workflows. Specific CE/ISO declarations are not listed in the provided catalog.

For precise incubation performance, the AELAB SHP Series biochemical incubator provides constant-temperature control and reproducible results across laboratory testing applications.
