Dissolution testers are used to check the rate and extent of dissolution of drugs from solid dosage forms such as tablets or capsules in a defined solvent. The AELAB RC Series provides reliable performance for routine pharmaceutical quality control and research applications.
The AELAB RC-1 model features a compact configuration designed for single-cup dissolution analysis, ensuring simple operation, stable speed regulation, and reproducible dissolution curves for drug release evaluation.
The AELAB RC-1 Dissolution Tester incorporates a transparent dissolution bath, a single dissolution cup, and a precision-machined paddle designed to meet pharmacopoeial requirements. The manual paddle flip mechanism provides controlled positioning during testing. The system is built on a rigid frame to ensure stable operation, minimal vibration, and consistent hydrodynamic conditions throughout the test.
The RC-1 stabilizes the paddle speed within ±2 rpm and maintains the dissolution medium temperature within ±0.3°C. The instrument agitates the dosage form in a controlled solvent environment, allowing users to quantify dissolution performance over time. Timing functions provide accurate control from 5 to 900 minutes, ensuring compliance with standard dissolution protocols.
The AELAB RC-1 supports external data recording through manual logging and laboratory LIMS workflows. Its stable control electronics ensure reliable integration into GLP-compliant testing environments.
| Model | Specifications |
|---|---|
| RC-1 | 1 cup and 1 paddle manual flip, 20~200 rpm, ±2 rpm, RT +45.0°C, 600 W, 18.5 kg |
The AELAB RC-1 is suitable for drug dissolution profiling, formulation stability studies, tablet and capsule QC testing, generic drug comparison, and research applications in pharmaceutical, academic, and regulatory laboratories.
The RC-1 is manufactured under strict AELAB quality controls and aligns with GLP practices. All mechanical and temperature control components undergo calibration verification to ensure consistent testing performance.
Specifications :
| Model | RC-1 |
|---|---|
| Cups and Paddle | 1 cup and 1 paddle manual flip |
| Speed Range | 20~200 rpm |
| Speed Precision | ±2 rpm |
| Temp. Range | RT +45.0°C |
| Temp. Precision | ±0.3°C |
| Timing Range | 5~900 min |
| Time Precision | ±0.5 min |
| Working Time | >24 h |
| Paddle Swing Amplitude | ±0.5 mm |
| Basket Swing Amplitude | ±1.0 mm |
| Power Consumption | 600 W |
| Power Supply | AC110/220V±10%, 50/60 Hz |
| External Size (W*D*H) mm | 260*300*480 |
| Package Size (W*D*H) mm | 560*410*590 |
| Gross Weight (kg) | 18.5 |
| Model | RC-1 |
|---|---|
| Cups and Paddle | 1 cup and 1 paddle manual flip |
| Speed Range | 20~200 rpm |
| Speed Precision | ±2 rpm |
| Temp. Range | RT +45.0°C |
| Temp. Precision | ±0.3°C |
| Timing Range | 5~900 min |
| Time Precision | ±0.5 min |
| Working Time | >24 h |
| Paddle Swing Amplitude | ±0.5 mm |
| Basket Swing Amplitude | ±1.0 mm |
| Power Consumption | 600 W |
| Power Supply | AC110/220V±10%, 50/60 Hz |
| External Size (W*D*H) mm | 260*300*480 |
| Package Size (W*D*H) mm | 560*410*590 |
| Gross Weight (kg) | 18.5 |
