AELAB GC-MS 3200 Gas Chromatograph–Mass Spectrometer (Quadrupole)

The AELAB GC-MS 3200 continues the evolution of the GC-MS product line, building upon the earlier GC-MS 3100 introduced in 2005. With more than a decade of development, customer feedback, and technological enhancement, the GC-MS 3200 offers improved performance, expanded functionality, and greater accessibility. Designed for qualitative and quantitative analysis, the system meets the needs of research, production laboratories, and advanced analytical workflows.

Switching between Electron Ionization (EI) and Chemical Ionization (CI) in the GC-MS 3200 is simple and efficient. The CI source extends analytical capability, particularly for combustible materials or compounds with weak EI responses. For selected pesticide analysis and other low-response matrices, the CI source enhances sensitivity and lowers the detection limit.

⚙️ Design & Construction

The AELAB GC-MS 3200 quadrupole mass spectrometer incorporates an upgraded ion optics system, redesigned magnetic focusing components, and optimized electron beam geometry. The ion source filament control circuit enables constant emission and constant reception modes, improving electron flow stability. The innovative voltage offset system enhances spatial electron distribution, increasing the signal-to-noise ratio by approximately 30%. A high-gain, low-dark-current electron multiplier with a polished parabolic dynode reduces neutral noise and improves high-mass response.

🔬 Working Principle / Testing Method

The GC-MS 3200 analyzes samples by separating components through the gas chromatograph before introducing them into the quadrupole mass spectrometer. In EI mode, electrons bombard molecules to generate characteristic fragmentation patterns. In CI mode, ion-molecule reactions provide softer ionization for molecular ion detection and improved sensitivity. Upgraded ion transmission optics and redesigned magnetic field geometry enhance beam focusing, reduce magnetic interference, and improve high-mass accuracy.

💡 Key Advantages

• Dual EI/CI ionization for broad compound coverage and enhanced molecular ion detection
• Upgraded feedback stabilization for improved long-term ion signal consistency
• Enhanced ion transmission efficiency through redesigned magnetic and optical components
• 30% increase in signal-to-noise ratio due to optimized electron beam distribution
• High-gain vertical focus detector for precise high-mass ion detection
• Reduced neutral particle interference improving resolution and mass accuracy
• Advanced quadrupole mass filtering with stable ion trajectory control

🔗 Connectivity & Integration

The provided catalog page does not contain communication or data output specifications. PC software compatibility, data export formats, and connectivity ports (USB, LAN, RS-232) must be confirmed from the full technical manual.

🧠 Model Insight

No model variations or alternate configurations are listed for the GC-MS 3200 in the provided catalog content.

🧪 Testing Applications

The AELAB GC-MS 3200 supports environmental testing, petrochemical analysis, forensics, pesticide monitoring, pharmaceutical impurity profiling, material characterization, food safety screening, and general research applications requiring high-resolution, high-sensitivity mass spectrometry.

Compliance & Quality Assurance

The GC-MS 3200 follows AELAB quality manufacturing protocols with precision quadrupole construction, stable ion source performance, and controlled optical alignment. Compliance with ISO and GLP analytical workflows is supported through stable long-term operation and robust instrument reliability.
