Good Innovation:
Integrate the atmospheric pressure and pressurized reaction, microwave, ultra-sonic wave and ultraviolet irradiation and other functions, giving full flexiblility;
High reproducibility：
Microwave automatic frequency conversion control, dual temperature control technology, and piezoelectric crystal pressure can ensure the accurate recordand representation of each reaction;
Severe safety:
Pressurized mode, intelligent safety pressure control system, real-time overpressure alarm and active pressure relief, outer vessel with composite fiber and other safety protection measures at the highest level;
Friendly operation:
inch color LCD touch screen, intelligent software, safe and remote control, and reaction process videography facility;
Reliable durability:
Multi-layer Teflon coating 316L stainless steel chamber and durable reaction container material ensure that all kinds of chemical reactions proceed smoothly;
Reliable experience:
20 years’ industry experience, ISO and CE certificated, and national leading numberof users;
Three energy sources microwave, ultrasonic and ultraviolet irradiation can be free combined and work together,and software control them timing on and off, achieving the synergistic effectby multi energies. UWave-2000 adopts immersion ultrasonic launcher, with an adjustable scope of ultrasound power: 0.800W, frequency ot28KHZ, and automatic frequency sweeping and frequency locking; With high energy density ultraviolet source(LED type UV lamp power is 100W, dominant wavelength is 365nm), it can conduct selective photochemical research. UWave-2000 is equipped with multiple reaction vessels, 50-2000ml glass flasks can meet the routine use, and optional multi-standards quartz reaction flasks can meet photochemical reaction under the ultraviolet radiation.
Specifications :
| Power supply | 220~240VAC 50/60Hz 9A |
| Microwave source | 2450MHz, 0~1000W, continuous, non-pulse and automatically
adjustable along with the temperature program, PID technology |
| Microwave oven chamber | Large volume, 316L stainless steel chamber,
applied with multi-layer anticorrosive PFA Teflon spray inside and outside |
| Temperature measuring
and control system |
Dual-channel temperature detection DTD technology, switchable control.lnfrared temperature sensor range 0~900℃, precision ±1℃,PT-100 resistor temperature sensor range 0~250℃, precision ±1℃ |
| Pressure measuring
and control system |
Piezoelectric crystal pressure sensor, pressure control range: 0~5MPa (750psl),precision of±0.01 MPa |
| Working temperature | Standard configuration instrument's maximum operating temperature is 300℃and the maximum theoretical operating temperature is 900℃(peculiar configuration).The standard maximum working temperature of high-pressure reactionis 230℃. |
| Working pressure | The standard maximum working pressure of high-pressure reaction is 2 MPa,with constant pressure control valve, and constant pressure value of 2 MPa. |
| UV light source system | lt can be equipped with high energy density ultraviolet source. LED type UV lamp power-100W, dominant wavelength is 365nm |
| Ultrasonic system | Immersion ultrasonic launcher, with adjustable scope of ultrasound power:0~800W, frequency of 28KHZ, and automatic frequency sweeping and frequency locking |
| Stirring system | Digital constant speed mechanical stirring, with rotation speed of 30~1600r/min.lt can realize real-time speed regulation and displays ±10r/grade, with torqueof 300 N.m. lt can stir clockwise or anticlockwise; Built-in magnetic stirringrotation speed of 0~800r/min, speed program is adjustable and of real-timedisplay. |
| Software system | With Windows software and 7-inch color LCD touch screen, it can make accuratesetting and real-time display of various parameters and curves, and can transmitthe reaction parameters and curves by connecting with the computer, and recordand realize the control or change of each reaction process unlimitedly; |
| Video system | Color image recording system is equipped, which can realize real-time display of reaction process through 7-inch color LCD screen. And it can realize the transmission and recording by connecting the computer. |
| Interface | USB2.0 Serial port |
| Exhaust system | Oven chamber is equipped with high-speed hot blast fan, with blast capacity of 3m³/min. 3-gear speed change will be made automatically according to the reaction situation |
| Atmospheric pressure reaction
vessel |
Standard 50~1000ml high borosilicate glass reaction vessel and condensation,reflux, charging accessories, optional 2000ml high borosilicate glass vessel,optional 50~1000ml quartz reaction vessel |
| High pressure reaction vessel | 100ml, 200ml and 500mI TFM high pressure digestion inner vessel, aerospace composite fiber explosion-proof outer vessel, high-strength alloy frame |
| Working environment temperature/humidity | 0~40°C/15~80% RH |
| Physical size of whole machine | 500 x 625 x 580 (Width×depth×height), 48kg |
| Power supply | 220~240VAC 50/60Hz 9A |
| Microwave source | 2450MHz, 0~1000W, continuous, non-pulse and automatically
adjustable along with the temperature program, PID technology |
| Microwave oven chamber | Large volume, 316L stainless steel chamber,
applied with multi-layer anticorrosive PFA Teflon spray inside and outside |
| Temperature measuring
and control system |
Dual-channel temperature detection DTD technology, switchable control.lnfrared temperature sensor range 0~900℃, precision ±1℃,PT-100 resistor temperature sensor range 0~250℃, precision ±1℃ |
| Pressure measuring
and control system |
Piezoelectric crystal pressure sensor, pressure control range: 0~5MPa (750psl),precision of±0.01 MPa |
| Working temperature | Standard configuration instrument's maximum operating temperature is 300℃and the maximum theoretical operating temperature is 900℃(peculiar configuration).The standard maximum working temperature of high-pressure reactionis 230℃. |
| Working pressure | The standard maximum working pressure of high-pressure reaction is 2 MPa,with constant pressure control valve, and constant pressure value of 2 MPa. |
| UV light source system | lt can be equipped with high energy density ultraviolet source. LED type UV lamp power-100W, dominant wavelength is 365nm |
| Ultrasonic system | Immersion ultrasonic launcher, with adjustable scope of ultrasound power:0~800W, frequency of 28KHZ, and automatic frequency sweeping and frequency locking |
| Stirring system | Digital constant speed mechanical stirring, with rotation speed of 30~1600r/min.lt can realize real-time speed regulation and displays ±10r/grade, with torqueof 300 N.m. lt can stir clockwise or anticlockwise; Built-in magnetic stirringrotation speed of 0~800r/min, speed program is adjustable and of real-timedisplay. |
| Software system | With Windows software and 7-inch color LCD touch screen, it can make accuratesetting and real-time display of various parameters and curves, and can transmitthe reaction parameters and curves by connecting with the computer, and recordand realize the control or change of each reaction process unlimitedly; |
| Video system | Color image recording system is equipped, which can realize real-time display of reaction process through 7-inch color LCD screen. And it can realize the transmission and recording by connecting the computer. |
| Interface | USB2.0 Serial port |
| Exhaust system | Oven chamber is equipped with high-speed hot blast fan, with blast capacity of 3m³/min. 3-gear speed change will be made automatically according to the reaction situation |
| Atmospheric pressure reaction
vessel |
Standard 50~1000ml high borosilicate glass reaction vessel and condensation,reflux, charging accessories, optional 2000ml high borosilicate glass vessel,optional 50~1000ml quartz reaction vessel |
| High pressure reaction vessel | 100ml, 200ml and 500mI TFM high pressure digestion inner vessel, aerospace composite fiber explosion-proof outer vessel, high-strength alloy frame |
| Working environment temperature/humidity | 0~40°C/15~80% RH |
| Physical size of whole machine | 500 x 625 x 580 (Width×depth×height), 48kg |
