The AELAB 4530F Single Beam 8 Lamps Turret Atomic Absorption Spectrophotometer offers high-precision quantitative metal analysis using flame and graphite furnace methods. Controlled by PC software, it provides automatic wavelength scanning, deuterium background correction, and comprehensive safety protection for accurate, repeatable laboratory measurements.
The AELAB 4530F Single Beam 8 Lamps Turret Atomic Absorption Spectrophotometer provides advanced quantitative elemental analysis for laboratories engaged in environmental, pharmaceutical, and metallurgical testing. It integrates a floated optical platform for enhanced shock resistance and long-term optical stability, while its 8-lamp automatic turret enables multi-element analysis with reduced setup time.
Completely PC-controlled, the system features automatic wavelength scanning, deuterium background correction, and built-in data processing with over 500 self-storage records. Its dual measurement capability supports both flame absorption and graphite furnace absorption for a broad range of detection limits and sample matrices.
The AELAB 4530F employs a single-beam optical configuration mounted on an integrated floated optical platform to minimize vibration effects. The all-metal titanium burner ensures durability, while the effective glass atomizer provides uniform atomization for high signal stability. The 8-position lamp turret allows automatic preheating and selection of hollow cathode lamps, optimizing operational efficiency. Compact housing and modular accessories ensure reliable, space-efficient installation in analytical laboratories.
The AELAB 4530F quantifies metal concentrations by measuring atomic absorption of light at element-specific wavelengths between 190–900 nm. The instrument utilizes a deuterium lamp for background correction, a PC-controlled scanning grating (1800 lines/mm), and precise regulation of the flame or graphite furnace temperature. Sample atomization occurs via an acetylene-air flame or electrically heated graphite tube. Measured absorbance values are converted to concentration using stored calibration curves.
The AAS 4530F multi-functional software workstation supports Windows systems, offering flexible parameter control, data storage, and report printing. USB and RS-232 interfaces allow easy data export and communication with PCs, printers, and optional accessories including hydride generator, chiller, and air compressor. Output formats include analytical results, parameter printouts, and spectrum diagrams.
| Model | Specifications |
|---|---|
| 4530F | 190–900 nm wavelength range, flame system with titanium burner, 8-lamp turret, PC control |
| 4510GF | Graphite furnace module, 3000 °C, ≥2000 °C/s heating, Cd ≤0.5×10⁻¹² g detection, 7000 W |
The AELAB 4530F is designed for trace and ultra-trace metal analysis in diverse matrices. Applications include environmental monitoring (water and soil), food safety, agricultural nutrient testing, pharmaceutical formulation, metallurgical alloy control, and biochemical research. It ensures compliance with ISO, GLP, and CE analytical quality standards.
All AELAB instruments conform to ISO 9001 manufacturing and CE safety directives. The AELAB 4530F is validated for GLP analytical traceability, with calibration protocols for wavelength accuracy and absorbance linearity traceable to certified reference standards.
Specifications :
| Technical Specifications | |
|---|---|
| Wavelength Range | 190–900 nm |
| Spectral Bandwidth | 0.1, 0.2, 0.4, 1.0 and 2.0 nm |
| Accuracy of Wavelength | ±0.15 nm |
| Receptivity of the Wavelength | ≤0.04 nm |
| Base Line Stability | ≤0.002 A/30 min (Cu) |
| Characteristic Viscosity | 0.02 µg/ml/1% (Cu) |
| Checking Limit | 0.004 µg/ml (Cu) |
| Preciseness | 0.50% |
| Grating | 1800 lines/mm |
| Inflamer | All-metal titanium burner |
| Atomizer | Effective glass atomizer |
| Lamp Stand | 8 |
| D₂ Background Correction Ability | When the background is 1 A, background ability should be deducted not less than 50 times; self-absorption background deduction method |
| Package Size | 860×705×755 mm (Main instrument) 1170×645×900 mm (Accessories) |
| Power Source | 220 V ±22 V AC |
| Flame System | |
|---|---|
| Acetylene Air Burner | 100 mm |
| Ignition Dynamic Baseline Drift | ≤0.006 A/30 min |
| (Cu) Characteristic Viscosity | ≤0.025 µg/ml/1% |
| Related Standard Deviation of the Accuracy | ≤0.5% (Cu, absorbance >0.8 A), detection limit Cu ≤0.008 µg/ml |
| Safety System | Automatic gas cut-off when pressure is insufficient, power off, flameout, or burner mismatch |
| 4510GF Graphite Furnace | |
|---|---|
| Highest Temperature | 3000 °C |
| Largest Temperature Rising Speed | ≥2000 °C/s |
| Characteristic Quantity | Cd ≤0.5×10⁻¹² g Cu ≤0.5×10⁻¹¹ g |
| Accuracy | Cu ≤3% Cd ≤3% |
| Size and Weight | 730×625×700 mm 79.3 kg |
| Safety System | Overcurrent protection; low air pressure alarm/protection; low cooling water flow alarm/protection |
| Power Source and Power | 220 V ±22 V AC 7000 W |
| Technical Specifications | |
|---|---|
| Wavelength Range | 190–900 nm |
| Spectral Bandwidth | 0.1, 0.2, 0.4, 1.0 and 2.0 nm |
| Accuracy of Wavelength | ±0.15 nm |
| Receptivity of the Wavelength | ≤0.04 nm |
| Base Line Stability | ≤0.002 A/30 min (Cu) |
| Characteristic Viscosity | 0.02 µg/ml/1% (Cu) |
| Checking Limit | 0.004 µg/ml (Cu) |
| Preciseness | 0.50% |
| Grating | 1800 lines/mm |
| Inflamer | All-metal titanium burner |
| Atomizer | Effective glass atomizer |
| Lamp Stand | 8 |
| D₂ Background Correction Ability | When the background is 1 A, background ability should be deducted not less than 50 times; self-absorption background deduction method |
| Package Size | 860×705×755 mm (Main instrument) 1170×645×900 mm (Accessories) |
| Power Source | 220 V ±22 V AC |
| Flame System | |
|---|---|
| Acetylene Air Burner | 100 mm |
| Ignition Dynamic Baseline Drift | ≤0.006 A/30 min |
| (Cu) Characteristic Viscosity | ≤0.025 µg/ml/1% |
| Related Standard Deviation of the Accuracy | ≤0.5% (Cu, absorbance >0.8 A), detection limit Cu ≤0.008 µg/ml |
| Safety System | Automatic gas cut-off when pressure is insufficient, power off, flameout, or burner mismatch |
| 4510GF Graphite Furnace | |
|---|---|
| Highest Temperature | 3000 °C |
| Largest Temperature Rising Speed | ≥2000 °C/s |
| Characteristic Quantity | Cd ≤0.5×10⁻¹² g Cu ≤0.5×10⁻¹¹ g |
| Accuracy | Cu ≤3% Cd ≤3% |
| Size and Weight | 730×625×700 mm 79.3 kg |
| Safety System | Overcurrent protection; low air pressure alarm/protection; low cooling water flow alarm/protection |
| Power Source and Power | 220 V ±22 V AC 7000 W |
