The AELAB TDP Series Single Punch Tablet Press Machine is perfect for producing tablets from pharmaceutical, chemical, and herbal powders. With higher motor power, stronger frame, and deeper filling capacity, it ensures stable performance and precise tablet formation. Operates manually or electrically for maximum flexibility.
Keywords: Single Punch Tablet Press, TDP Series, Pill Making Machine, Tablet Press for Pharma & Lab.
The AELAB TDP Series Single Punch Tablet Press Machine is a high-performance solution designed for pressing various powder materials into uniform tablets. Ideal for pharmaceutical production, chemical processing, R&D laboratories, and hospital pharmacies, this compact yet powerful press delivers outstanding efficiency and reliability.
Featuring enhanced motor power, reinforced structural strength, and increased filling depth, the TDP Series offers a wider range of tablet sizes and weights. With its dual manual and electric operation modes, production can continue even during power outages. This machine is capable of producing tablets from traditional Chinese medicine, Western medicine, herbal supplements, chemical powders, and similar products.
Engineered for durability and precision, the TDP Series is easy to operate, maintain, and adjust, making it a preferred choice for small to medium-scale tablet manufacturing.
Keywords: Single Punch Tablet Press, TDP Series Tablet Press, Pharmaceutical Tablet Press Machine, Manual and Electric Tablet Press, Laboratory Tablet Press, Pill Press Machine, Tablet Making Machine.
Features:
Dual Operation – Works with both manual and electric modes for uninterrupted production.
Enhanced Performance – Increased motor power and reinforced frame for longer lifespan.
Deeper Filling Depth – Supports a wider range of tablet sizes and weights.
Compact Design – Space-saving and lightweight for easy installation and mobility.
Versatile Applications – Suitable for pharmaceuticals, chemicals, herbal supplements, and R&D use.
Specifications :
| No. | Item | TDP-1.5 | TDP-5 | TDP-6 |
| 1 | Max .press strength(KN) | 15 | 50 | 60 |
| 2 | Max .tablet diameter(mm) | 12 | 20 | 25 |
| 3 | Max .filling depth(mm) | 12 | 18 | 16 |
| 4 | Productive capacity(Pcs/Hour) | 4700 | 4500 | 4000 |
| 5 | Motor power(kw) | 0.25 | 0.55 | 1.1 |
| 6 | Turning speed(r/min) | 1400 | 1400 | 1400 |
| 7 | Weight (kg) | 92.5 | 125 | 150 |
| 8 | Length*Width*Height(mm) | 570x380x630 | 650x440x650 | 700x500x900 |
| No. | Item | TDP-1.5 | TDP-5 | TDP-6 |
| 1 | Max .press strength(KN) | 15 | 50 | 60 |
| 2 | Max .tablet diameter(mm) | 12 | 20 | 25 |
| 3 | Max .filling depth(mm) | 12 | 18 | 16 |
| 4 | Productive capacity(Pcs/Hour) | 4700 | 4500 | 4000 |
| 5 | Motor power(kw) | 0.25 | 0.55 | 1.1 |
| 6 | Turning speed(r/min) | 1400 | 1400 | 1400 |
| 7 | Weight (kg) | 92.5 | 125 | 150 |
| 8 | Length*Width*Height(mm) | 570x380x630 | 650x440x650 | 700x500x900 |
