The AELAB SK-0330-Pro and SK-0180-Pro Multifunctional Orbital Decolorizing Shakers provide precision, stability, and uniform shaking performance for demanding laboratory workflows. Designed for mixing culture dishes, flasks, and beakers, these compact shakers deliver smooth orbital motion, advanced safety features, and brushless DC motor technology for long-term reliability.
The AELAB Orbital Decolorizing Shaker creates circular orbital motion, generating consistent agitation for sample mixing and extraction. By maintaining a stable shaking pattern and uniform speed, the device ensures optimal aeration and homogeneous mixing of liquid samples. The brushless DC motor provides quiet, durable operation, while integrated speed and time controls ensure precise workflow management.
The SK-0330-Pro and SK-0180-Pro incorporate durable platforms compatible with flasks, culture dishes, and standard laboratory vessels. Each model uses a maintenance-free Brushless DC Motor to deliver stable orbital movement. LCD displays for speed and time allow clear monitoring, while compact footprints support installation in CO₂ incubators and environmental chambers. The platforms accommodate multiple vessel formats, and both units feature integrated over-speed protection and robust housing suited for routine laboratory operation.
Both AELAB orbital shakers operate by generating controlled orbital motion at fixed orbital diameters (10mm for SK-0330-Pro and 4mm for SK-0180-Pro). The brushless motor ensures smooth acceleration, uniform rotation, and consistent agitation across the entire speed range. Speed and time parameters are set via the LCD interface, and the built-in microprocessor regulates motion to maintain constant rpm during long mixing cycles. The system is suitable for sample aeration, extraction, dissolution, and biological culture mixing.
Both models include RS232 ports for PC connectivity, data logging, and remote parameter control. Compatible software allows export of operational logs, integration into GLP documentation systems, and connection to laboratory automation workflows.
| Model | Specifications |
|---|---|
| SK-0330-Pro | 10mm orbital diameter, 7.5kg load capacity, 100–500rpm speed range, 12kg weight |
| SK-0180-Pro | 4mm orbital diameter, 2.5kg load capacity, 100–800rpm speed range, 8.1kg weight |
Suitable for microbiology laboratories, cell culture operations, environmental testing workflows, sample extraction processes, aeration and mixing of flasks, dye decolorization experiments, and general liquid agitation tasks. The compact structure enables installation inside CO₂ incubators and temperature-controlled chambers for specialized studies.
The AELAB SK-Pro Series complies with laboratory equipment safety standards, featuring IP21/IP20 protection, precision manufacturing tolerances, and calibration traceability. All units undergo AELAB quality assurance procedures to ensure reliable performance in GLP, research, and industrial environments.
Specifications :
| Specifications | SK-0330-Pro | SK-0180-Pro |
|---|---|---|
| Orbital diameter | 10mm | 4mm |
| Max. load capacity (with platform) | 7.5kg | 2.5kg |
| Motor type | Brushless DC motor | Brushless DC motor |
| Motor input power | 28W | 28W |
| Motor output power | 15W | 15W |
| Speed range | 100–500rpm | 100–800rpm |
| Speed display | LCD | LCD |
| Timer display | LCD | LCD |
| Time settings range | 1min–99h59min | 1min–99h59min |
| Voltage, Frequency | 100–240V, 50/60Hz | 100–240V, 50/60Hz |
| Power | 30W | 30W |
| Weight | 12kg | 8.1kg |
| Permissible ambient temperature and humidity | 5–40°C, ≤80%RH | 5–40°C, ≤80%RH |
| Dimension (W × D × H) | 370 × 420 × 100mm | 300 × 340 × 100mm |
| Protection class | IP21 | IP20 |
| Data connector | RS232 | RS232 |
| Specifications | SK-0330-Pro | SK-0180-Pro |
|---|---|---|
| Orbital diameter | 10mm | 4mm |
| Max. load capacity (with platform) | 7.5kg | 2.5kg |
| Motor type | Brushless DC motor | Brushless DC motor |
| Motor input power | 28W | 28W |
| Motor output power | 15W | 15W |
| Speed range | 100–500rpm | 100–800rpm |
| Speed display | LCD | LCD |
| Timer display | LCD | LCD |
| Time settings range | 1min–99h59min | 1min–99h59min |
| Voltage, Frequency | 100–240V, 50/60Hz | 100–240V, 50/60Hz |
| Power | 30W | 30W |
| Weight | 12kg | 8.1kg |
| Permissible ambient temperature and humidity | 5–40°C, ≤80%RH | 5–40°C, ≤80%RH |
| Dimension (W × D × H) | 370 × 420 × 100mm | 300 × 340 × 100mm |
| Protection class | IP21 | IP20 |
| Data connector | RS232 | RS232 |
