40KHz Ultrasonic Mode for Intensive Rinse-Professional for Blind Holes Cleaning
DEGAS
Intermitted Pause to Remove Ultrasonic Fatigue-Improve Ultrasonic Cleaning Performance
TIME
1 ~60minutes or Always on-Encoded Control of high-precision
HEAT
0-80°C Temperature Range Encoded Control of high-precision
Ultrasonic Mode
The ultrasonic mode can be selected by pressing the <Modes Selection & Time Setting Knob> slightly to make the <Ultrasonic Indicator> turn on; and shall be started by rotating the knob to the right to make one < time value indicator> of the < time indicating column> flicker, and shall be stopped by rotating the knob to the left to make the < time value indicator> on the <OFF> position.
Degas Mode
The degas mode can be selected by pressing the < Modes Selection & Time Setting Knob> slightly to make the < Degas Indicator> turn on; and shall be started by rotating the knob to the right to make one < Time Value Indicator> of the <Time Indicating Column> flicker, and shall be stopped by rotating the knob to the left to make the < Time ; Value Indicator> be on the <OFF> position.
Heating Function
Heating can be started by rotating the < Temperature Setting Knob> slightly to the right to make one < Tempera- ture Value Indicator>’ of the <Temperature Indicating Column>. flicker; and shall be suspended by rotating the knob to the left to make the preset temperature be lower than the actual temperature(meanwhile the < temperature Value Indicator> of the < Temperature Indicating Column> shall stop flickering, however, it shall flicker again and heating shall be restarted again when the actual tempera- ture becomes lower than the preset temperature), and shall be stopped by rotating the knob to the left to make the <Temperature Value Indicator> be on the <OFF> position.
Specifications :
| Model No. | Tank Size
(mm) |
Overall Size
(mm) |
Capacity | Freq | Ultrasonic Power | Heating Power
(W) |
Box Size
(mm) |
N.W.
(KG) |
G.W./Box (KG) | Package | Carton Size
(mm) |
G.W./
Carton (KG) |
| AE-10 | 180*140*85 | 220*170*218 | 2 | 40 | 60 | 100 | 270*235*285 | 2.52 | 2.8 | 4Box/Carton | 560*490*305 | 11.7 |
| AE-20 | 240*140*100 | 270*160*220 | 3.2 | 40 | 120 | 100 | 335*240*290 | 3.2 | 3.94 | 4Box/Carton | 500*350*610 | 16.1 |
| AE-30 | 300*155*150 | 330*180*280 | 6.5 | 40 | 180 | 300 | 435*365*350 | 5.2 | 5.85 | 1Box/Carton | 435*265*350 | 5.85 |
| AE-40 | 300*240*150 | 330*270280 | 10 | 40 | 240 | 300 | 430*335*355 | 6.5 | 7.56 | 1Box/Carton | 430*335*355 | 7.56 |
| AE-60 | 330*300*150 | 360*330*280 | 15 | 40 | 360 | 400 | 455*390*355 | 8.2 | 9.3 | 1Box/Carton | 455*390*355 | 9.3 |
| AE-80 | 500*300*150 | 530*330*280 | 22 | 40 | 480 | 500 | 660*420*355 | 10.4 | 12.47 | 1Box/Carton | 660*420*355 | 12.47 |
| AE-100 | 500*300*200 | 530*330*330 | 30 | 40 | 600 | 500 | 660*420*407 | 12 | 14.3 | 1Box/Carton | 660*420*407 | 14.3 |
| Model No. | Tank Size
(mm) |
Overall Size
(mm) |
Capacity | Freq | Ultrasonic Power | Heating Power
(W) |
Box Size
(mm) |
N.W.
(KG) |
G.W./Box (KG) | Package | Carton Size
(mm) |
G.W./
Carton (KG) |
| AE-10 | 180*140*85 | 220*170*218 | 2 | 40 | 60 | 100 | 270*235*285 | 2.52 | 2.8 | 4Box/Carton | 560*490*305 | 11.7 |
| AE-20 | 240*140*100 | 270*160*220 | 3.2 | 40 | 120 | 100 | 335*240*290 | 3.2 | 3.94 | 4Box/Carton | 500*350*610 | 16.1 |
| AE-30 | 300*155*150 | 330*180*280 | 6.5 | 40 | 180 | 300 | 435*365*350 | 5.2 | 5.85 | 1Box/Carton | 435*265*350 | 5.85 |
| AE-40 | 300*240*150 | 330*270280 | 10 | 40 | 240 | 300 | 430*335*355 | 6.5 | 7.56 | 1Box/Carton | 430*335*355 | 7.56 |
| AE-60 | 330*300*150 | 360*330*280 | 15 | 40 | 360 | 400 | 455*390*355 | 8.2 | 9.3 | 1Box/Carton | 455*390*355 | 9.3 |
| AE-80 | 500*300*150 | 530*330*280 | 22 | 40 | 480 | 500 | 660*420*355 | 10.4 | 12.47 | 1Box/Carton | 660*420*355 | 12.47 |
| AE-100 | 500*300*200 | 530*330*330 | 30 | 40 | 600 | 500 | 660*420*407 | 12 | 14.3 | 1Box/Carton | 660*420*407 | 14.3 |
