How is calibration done?

Calibration is performed using standard calibration slides and adjusting interpupillary distance and zoom settings for accurate measurements.

Is the device GMP compliant?

Yes, AELAB stereo zoom microscopes are designed following international quality standards, suitable for GMP-regulated environments.

How long is the warranty?

All AELAB microscopes come with a 12-month standard warranty, extendable upon request.

AELAB Stereo Zoom Microscope AE-SZ650BP Series – Precision 3D Imaging

AELAB Stereo Zoom Microscope AE-SZ650BP Series – Precision 3D Imaging

The AELAB Stereo Zoom Microscope AE-SZ650BP Series delivers crystal-clear three-dimensional imaging with exceptional depth of field and working distance. Built with ergonomic design and advanced optical systems, it is ideal for long-term laboratory observation, offering precise performance for electronics inspection, biological research, and industrial quality control.

Modles : AE-SZ650BP、AE-SZ650B2L、AE-SZ680BP、AE-SZ680B2L、AE-SZ680TP、AE-SZ680T2L、AE-SZ810BP、AE-SZ810B2L、AE-SZ810TP、AE-SZ810T2L

Quantity:

Send Email

A stereo zoom microscope provides three-dimensional views of objects through two separate optical paths. It features adjustable zoom lenses that allow for a wide range of magnifications. This type of microscope offers a large working distance and depth of field, making it ideal for inspecting and manipulating larger samples, such as electronic components or biological specimens. The stereo zoom microscope is commonly used in fields like electronics, manufacturing, and biological research.

Feature：

Outstanding Ergonomic Design

SZ680/810 35°viewing angle, SZ650 40°viewing angle, suitable for long-term sitting observation.
330mm×300mmbig stand, high stability , apply to all kinds of anatomy of specimen.

Top Optical & Mechanical Design

Greenough optical system, built-in rotating shaft zoom system.
No tilting Image in left &right light path in complete pupillary distance , No dizziness feeling after long time observing.
(patent number: 201320807246.0)
Stereo angle for left & right light path is 12°, stereoscopic effect, large viewing field, high zoom ration.

Excellent Technology And Quality

High resolution, large depth of field, excellent color restoration and contrast.
Operation comfortable(manufactured by high-precision machine, excellent assembly technology ).
High- end material(PC resin cover, aluminium alloy ,copper alloy parts, austenite stainless steel driving parts).

International Level Appearance Design

Elegant shape , high-end and integrated appearance design， comfortable operation.

Various Accessories,Complete Function.

Different video output connectors, built-in digital image model.
Illumination optional: LED, halogen lamp, cold light source etc. (100V-240V wide voltage input).
Various professional stands and operating attachments.

🔬 How It Works?

The AE-SZ650BP Series uses a Greenough optical system with dual optical paths to produce sharp, true-to-life 3D images. Its rotating shaft zoom system ensures seamless magnification changes without image distortion. A large working distance allows researchers to manipulate specimens directly under the lens, making it highly suitable for electronics assembly, dissection, and fine detail inspection.

💡 Advantages

Ergonomic viewing angle for fatigue-free observation
High-resolution optics with excellent color restoration
Large depth of field and wide zoom range for versatile applications
Multiple illumination options to suit diverse specimens
Durable, high-end construction with long service life
Optional trinocular head for digital imaging and documentation

🔍 Recommended Models by Use Case

AE-SZ650BP: Best for educational labs and routine inspections
AE-SZ680 Series: Ideal for research centers requiring flexible zoom ratios
AE-SZ810 Series: Recommended for advanced quality control, precision manufacturing, and detailed biological analysis

🧪 Ideal For

Biological and medical research laboratories
Electronics and semiconductor inspection
Quality control departments in manufacturing
Forensic science and material analysis labs
Food and chemical laboratories for sample testing

Specifications :

Main Technical Specification

Model	AE-SZ650	AE-SZ680	AE-SZ810
Objectives Zoom Range	0.7X-4.5X	0.68X-4.7X	0.65X-5.3X
Zoom Ratio	1 : 6.5	1 : 6.8	1 : 8.1
Field Diameter (mm)	Φ22	Φ23	Φ24
Working Distance (mm)	110	110	110
Stereo Angle ( °)	12	12	12
Viewing Angle ( °)	40	35	35
Interpupillary Adjustable Distance (mm)	50-75	50-75	50-75
Video Output Distribution	NO	100%（0:100 standard）
Video Output Distribution	NO	50:50 optional
Guide Rail Stand Focusing Distance (mm)	80
Pillar Stand Focusing Distance (mm)	115

AE-SZ650 Series Objective & Eyepiece Parameter List (0.7×-4.5×)

Additional Objective		0.5X	1X(built-in)	2X
W.D		189mm	110mm	36mm
10XEyepiece/Φ22mm	Magnification	3.5～22.5	7～45	14～90
10XEyepiece/Φ22mm	Field dia. (mm)	62.9～9.8	31.43～4.89	15.71～2.44
15XEyepiece/Φ16mm	Magnification	5.25～33.75	10.5～67.5	21～135
15XEyepiece/Φ16mm	Field dia. (mm)	45.71～7.11	22.86～3.56	11.43～1.78
20XEyepiece/Φ12mm	Magnification	7～45	14～90	28～180
20XEyepiece/Φ12mm	Field dia.(mm)	34.28～5.33	17.14～2.67	8.57～1.33

AE-SZ680 Series Objective & Eyepiece Parameter List (0.68×-4.7×)

Additional Objective		0.5X	1X(built-in)	2X
W.D		189mm	110mm	36mm
10XEyepiece/Φ23mm	Magnification	3.4～23.5	6.8～47	13.6～94
10XEyepiece/Φ23mm	Field dia. (mm)	67.65～9.79	33.82～4.89	16.91～2.46
15XEyepiece/Φ16mm	Magnification	5.1～35.25	10.2～70.5	20.4～141
15XEyepiece/Φ16mm	Field dia. (mm)	47.06～6.81	23.53～3.40	11.76～1.70
20XEyepiece/Φ12mm	Magnification	6.8～47	13.6～94	27.2～188
20XEyepiece/Φ12mm	Field dia.(mm)	35.294～5.11	17.65～2.55	8.82～1.28

AE-SZ810 Series Objective & Eyepiece Parameter List (0.65×-5.3×)

Additional Objective		0.5X	1X(built-in)	2X
W.D		189mm	110mm	36mm
10XEyepiece/Φ24mm	Magnification	3.3～25.5	6.6～51	13.2～102
10XEyepiece/Φ24mm	Field dia. (mm)	72.73～9.41	36.36～4.71	18.18～2.35
15XEyepiece/Φ16mm	Magnification	4.95～38.25	9.9～76.5	19.8～153
15XEyepiece/Φ16mm	Field dia. (mm)	48.48～6.27	24.24～3.14	12.12～1.57
20XEyepiece/Φ12mm	Magnification	6.6～51	13.2～102	26.4～204
20XEyepiece/Φ12mm	Field dia. (mm)	39.64～4.71	18.18～2.35	9.09～1.18

AE-SZ650/680/810 Series Zoom Stereo Microscope Outfit

Items		AE- SZ650BP	AE- SZ650B2L	AE- SZ680BP	AE- SZ680B2L	AE- SZ680TP	AE- SZ680T2L	AE- SZ810BP	AE- SZ810B2L	AE- SZ810TP	AE- SZ810T2L
Main Body	Binocular	●	●	●	●			●	●
Main Body	Trinocular					●	●			●	●
10XEyepiece/Φ22mm		●●	●●
10XEyepiece/Φ23mm				●●	●●	●●	●●
10XEyepiece/Φ24mm								●●	●●	●●	●●
15XEyepiece/Φ16 mm		○○	○○	○○	○○	○○	○○	○○	○○	○○	○○
20XEyepiece/Φ12mm		○○	○○	○○	○○	○○	○○	○○	○○	○○	○○
0.5X/0.75X/2X Objective		○	○	○	○	○	○	○	○	○	○
Focusing unit		●	●	●	●	●	●	●	●	●	●
No light		●		●		●		●		●
Reflecting 3W LED			●		●		●		●		●
Transmitting 3W LED			●		●		●		●		●
Black & white Plate		●	●	●	●	●	●	●	●	●	●
Glass Plate			●		●		●		●		●
Arm stand		●	●	●	●	●	●	●	●	●	●
Pillar stand		○	○	○	○	○	○	○	○	○	○
Focusing Arm stand		○	○	○	○	○	○	○	○	○	○
Base (330×300mm)		●	●	●	●	●	●	●	●	●	●
C-mount 0.5X，0.7X，1X						○	○			○	○

Note："●" In Table Is Standard Outfits, "○" Is Optional Accessories.
