AELAB TC2000-G1/G2/G3 Thermal Cycler Gradient PCR System

The AELAB TC2000-G1/G2/G3 Thermal Cycler Gradient is an indispensable laboratory instrument in the field of molecular biology, used for sequencing, cloning, gene expression studies, and mutation analysis. It plays a key role in clinical research, environmental science, food testing, agricultural genetics, and related disciplines.

Designed with advanced gradient temperature control, high-performance Peltier refrigeration and heating, and a 10-inch touchscreen interface, the TC2000-G Series ensures precise and reproducible PCR temperature cycling. Multi-module configurations enable laboratories to run several PCR gradient programs simultaneously, optimizing diverse experimental requirements.

⚙️ Design & Construction

The TC2000-G Series employs robust Aluminum carrier modules and high-efficiency Peltier elements for rapid heating and cooling cycles. Each model integrates a full-color 10.1-inch LCD (1280×800) touchscreen, supporting intuitive parameter entry and real-time monitoring. The system incorporates a self-adaptive pressure hot lid accommodating different tube heights and offers reliable Block/Tube temperature control for enhanced uniformity.

🔬 Working Principle / Testing Method

The thermal cycler uses precise Peltier-driven temperature modulation to perform denaturation, annealing, and extension cycles essential for DNA amplification. Gradient span capability (up to 42°C depending on model) enables users to test multiple annealing temperatures within a single run. Advanced edge-temperature compensation ensures uniform heat distribution, while internal algorithms maintain ±0.1°C accuracy and ±0.2°C uniformity.

💡 Key Advantages

• Multi-block platform allows independent gradient PCR runs in parallel
• High temperature ramping rate of 5°C/sec accelerates protocol completion
• Power-failure recovery automatically resumes incomplete cycles
• Capacity to store over 20,000 programs for extensive method libraries
• USB flash support for exporting data, uploading software, and sharing protocols
• Optimized workflow with 30 programmable steps and 199 cycles per protocol
• Compatible with 0.2 mL tubes, PCR-8 strips, and 96-well plates

🔗 Connectivity & Integration

The TC2000-G1/G2/G3 models include USB and WiFi interfaces for file transfer, remote control, and GLP-compliant data management. Users can upload new firmware or save PCR logs via U-disk, supporting digital integration with laboratory information systems.

🧠 Model Insight

🧪 Testing Applications

This system supports medical diagnostics, microbial identification, genetic variation studies, agricultural breeding research, food pathogen testing, forensic DNA analysis, environmental microbiology, drug development studies, and paleogenetic or evolutionary research.

Compliance & Quality Assurance

Manufactured under AELAB quality management protocols, the TC2000-G Series supports GLP workflows, traceable calibration, and conforms to international laboratory equipment standards. Its stable performance ensures reliable amplification conditions for sensitive PCR assays.
