Horizontal Shaking Incubators AE-LYZ-211B Series

Horizontal shaking incubators combine temperature control with a side-to-side shaking motion to evenly mix and grow cultures. They are used for applications like microbial culture and enzyme reactions, providing consistent agitation and temperature to enhance experimental results.

Modles : AE-LYZ-211B, AE-LYZ-211C

Quantity:

Send Email

Horizontal shaking incubators are devices that provide a controlled environment for growing cultures while gently shaking them from side to side. They maintain precise temperature conditions and offer adjustable shaking speeds to enhance mixing and growth. Their horizontal shaking motion ensures even agitation, which is ideal for applications like microbial cultures and biochemical reactions.

Features:

Integrated with incubator and shaker to save space and cost.
High quality steel shell, polished stainless steel chamber.
Large LCD screen to display temperature and shaking speed.
With operation data memory function to eliminate faulty operation.
Non-volatile memory saves settings during a power outage and automaticallyrestarts the unit as originally programmed after power is restored.
Auto-stop operation when door is opened. Strong air spring rod with easy opening and closing.
Brushless DC motor, more stable and reliable.
With UV Sterilizer.
Equipped with power leakage protection.

Specifications :

Model	AE-LYZ-211B	AE-LYZ-211C
Shaking Speed（rpm）	20-300
Speed Accuracy（rpm）	±1
Swing Amplitude（mm）	Ф26
Standard Configuration	500ml×28	2000ml×12
Maximum Capacity	250ml×36 or 500ml×28 or1000ml×18	1000ml×18 or 2000ml×12 or 3000ml×8 or 5000ml×6
Tray Size（mm）	920×510
Timing Range	1~9999min
Temperature Range（℃）	4-60 (Cooling)	4-60(Cooling)
Temperature Accuracy （℃）	±0.1
Temperature Uniformity（℃）	±1
Display	LCD
Tray Included	1
Exterior Size(W×D×H)mm	120×74×80	120×74×100
Net Weight(kg)	174	183
Power Rating（W）	866	951
VolumeW×D×H(mm)	970×565×280 (155L)	970×565×480 (265L)
Power Supply	AC220V±10% , 50-60Hz
