AELAB PVDF Syringe Filter – Hydrophilic & Hydrophobic Lab Filtration FBS Series

AELAB PVDF Syringe Filter – Hydrophilic & Hydrophobic Lab Filtration FBS Series

The AELAB PVDF Syringe Filter provides high-quality filtration with options for both hydrophilic and hydrophobic membranes. Designed for HPLC, pharmaceutical, and biological applications, these filters ensure accuracy, durability, and consistent lab performance. Available in multiple pore sizes and diameters, they are the ideal choice for professionals seeking efficiency and reliability.

Modles : FBS Series

Quantity:

Send Email

The AELAB PVDF Syringe Filter is engineered with dual membrane options—hydrophobic and hydrophilic—to suit diverse laboratory needs. Hydrophobic membranes are ideal for HPLC sample preparation and biological filtration, while hydrophilic membranes ensure aseptic filtration in pharmaceutical and biotech applications. With diameters of 13mm, 25mm, and 30mm, these filters provide flexibility for different sample volumes.

🔬 How It Works?

The AELAB PVDF Syringe Filter uses advanced membrane technology to ensure precise separation. Hydrophobic filters minimize protein binding, making them ideal for HPLC sample preparation, while hydrophilic filters are optimized for sterile filtration of aqueous and biological solutions. The leak-proof polypropylene housing guarantees sample integrity and prevents solvent loss during operation.

💡 Advantages

Dual options: hydrophobic & hydrophilic membranes
Superior chemical compatibility (water, acetonitrile, methanol)
Leak-proof sealing ensures reliable operation
Large membrane area supports efficient filtration
Manufactured under ISO 9001 certified standards
Available in multiple sizes for flexible lab applications

🔍 Recommended Models by Use Case

Educational Labs: 13 mm filters with 0.45 μm pore size for routine demonstrations and training.
Research Centers: 25 mm filters with 0.22 μm pore size for high-precision HPLC sample preparation.
QC Departments: 30 mm hydrophilic filters for large-volume pharmaceutical or food safety testing.

🧪 Ideal For

HPLC sample preparation
Pharmaceutical and biotechnology labs
Biological and aseptic filtration processes
Food and chemical analysis
Industrial R&D and academic research

Certificate of Analysis

Hydrophilic PVDF Syringe Filter, 13mm, 0.22µm, Non-Sterile	Part Number: FBS13PVDF022L
	Lot Number: 2023060102

ISO 9001 Quality Standard

The product was manufactured in the Filter Bioscience Membrane Technology facility whose Quality Management System is approved by an accredited registering body to the ISO 9001 Quality Systems Standard.

Syringe Filter Lot Characterization
Membrane material and Pore size	PVDF-L 0.22µm
Wettability	Hydrophilic
Housing Material	Polypropylene
Inlet/Outlet	Female Luer lock/Male Luer silp
Maximum Operating Temperature(°C)	50
Filtration area(cm²)	≈1
Holdup volume (μl)	15
Volume Throughput (ml)	100
Bubble point(mpa)	0.18
Flow Rate (mL/min/cm2 at 1 bar)	12
Burst pressure(psi)	100
Package	100pcs/pk

HPLC Test
Conditions	Two ml of the solvent were applied to the filter, 100ul of the filtrate were injected to the HPLC
Eluent A	Water
Eluent B	Acetonitrile
Eluent C	Methanol
Gradient	10%-95% B in 25 minutes
Sensitivity	-5 to 10 mAU at 254nm
Column	Waters Sun Fire C18,5μm,4.6×150mm

Specifications :

Item	Description	Packaging (pcs/pk)
PVDF Syringe Filter (Hydrophobic)
FBS13PVDF022H	Pore:0.22μm	Diameter: 13mm	100
FBS13PVDF045H	Pore:0.45μm	Diameter: 13mm	100
FBS25PVDF022H	Pore:0.22μm	Diameter: 25mm	100
FBS25PVDF045H	Pore:0.45μm	Diameter: 25mm	100
FBS30PVDF022H	Pore:0.22μm	Diameter: 30mm	100
FBS30PVDF045H	Pore:0.45μm	Diameter: 30mm	100
PVDF Syringe Filter (Hydrophilic)
FBS13PVDF022L	Pore:0.22μm	Diameter: 13mm	100
FBS13PVDF045L	Pore:0.45μm	Diameter: 13mm	100
FBS25PVDF022L	Pore:0.22μm	Diameter: 25mm	100
FBS25PVDF045L	Pore:0.45μm	Diameter: 25mm	100
FBS30PVDF022L	Pore:0.22μm	Diameter: 30mm	100
FBS30PVDF045L	Pore:0.45μm	Diameter: 30mm	100

Item	Description	Packaging (pcs/pk)
PVDF Syringe Filter (Hydrophobic)
FBS13PVDF022H	Pore:0.22μm	Diameter: 13mm	100
FBS13PVDF045H	Pore:0.45μm	Diameter: 13mm	100
FBS25PVDF022H	Pore:0.22μm	Diameter: 25mm	100
FBS25PVDF045H	Pore:0.45μm	Diameter: 25mm	100
FBS30PVDF022H	Pore:0.22μm	Diameter: 30mm	100
FBS30PVDF045H	Pore:0.45μm	Diameter: 30mm	100
PVDF Syringe Filter (Hydrophilic)
FBS13PVDF022L	Pore:0.22μm	Diameter: 13mm	100
FBS13PVDF045L	Pore:0.45μm	Diameter: 13mm	100
FBS25PVDF022L	Pore:0.22μm	Diameter: 25mm	100
FBS25PVDF045L	Pore:0.45μm	Diameter: 25mm	100
FBS30PVDF022L	Pore:0.22μm	Diameter: 30mm	100
FBS30PVDF045L	Pore:0.45μm	Diameter: 30mm	100

No download files available for this product.

Product Photos

Frequently Asked Questions

1What makes the AELAB PVDF syringe filter suitable for HPLC?

Its hydrophobic, low protein-binding membrane ensures clean filtrates, preventing interference in chromatographic analysis.

2Its hydrophobic, low protein-binding membrane ensures clean filtrates, preventing interference in chromatographic analysis.

Yes, the strong polypropylene housing and robust flow rate make them suitable for moderately viscous samples in biological and chemical labs.

3How do hydrophilic and hydrophobic versions differ in use?

Hydrophilic membranes are ideal for aqueous solutions and sterile filtration, while hydrophobic membranes are best for solvents, air, and protein-sensitive samples.

4What quality standards do AELAB syringe filters comply with?

They are manufactured in ISO 9001 certified facilities, ensuring consistent quality and compliance with international laboratory standards.
